MPO Patch Panel Specification

Product description: MPO patch panel supports maximum 4xMPO cassettes in 1U,8 cassettes in 2U and 16 cassettes in 4U.Each MPO cassettes available in 12 or 24xLC connectors, which provides max.96 ports in 1U,192 ports in 2
INQUIRY EMAIL

Features

l Suitable for 19 inch standard frame

l Suitable for ribbon and single fiber

l Compact design for space saving

l Front mark on the plate is easy for identification and operation.

l Standard size, light weight and reasonable structure.

l Easy for management and operation

l Modular design, which can be used in multiple module boxes and configured in MPO-LC Type Distribution Box

l The MPO ribbon multi-core fiber is divided into multiple lc interfaces to realize parallel conversion of MPO-LC

Applications

l Telecommunications subscriber loop

l Fiber to the home (FTTH)

l LAN/WAN

l CATV

Mechanical and environmental characteristics

Specifications and Models

Model	MPO-LC Type Cassette Quantity	Height	Dimension(LxWxH)
MPO-LC	4	1U	482mmx350mmx44.5mm
MPO-LC	8	2U	482mmx350mmx88.9mm
MPO-LC	16	4U	482mmx350mmx177.8mm
