100G/200G CFP Muxponder

Product Overview

100G/200G CFP muxponder is a 12-channel 10G or 24-channel 10G Ethernet signal aggregation launched by Anycoms to meet the high-bandwidth interconnects of optical transmission and data center. It follows the G.709 protocol multiplexing mapping and framing processing. After the 100G/200G coherent optical module completes the photoelectric conversion to the C-band coherent signal, to realize the input and output of the coherent signal. Provide high-quality solutions for transmissions such as insufficient margins of the existing systems and long optical cable transmission distances.

Features

l100G CFP muxponder supports up to 12 channels of 10G Ethernet client side and 1+1 protection, line side 1 channel 100G coherent module access.

l200G CFP muxponder supports up to 24 channels of 10G Ethernet client side and 1+1 protection, line side 1 channel 200G coherent module access.

lSupport OTN services such as OTU1, OTU2e, OTU3, OTU4, etc.

lSupport OTN package, mapping and overhead defined by G.709.

lThe 100G/200G line side interface adopts polarization multiplexing and QPSK/QAM modulation to reduce the transmission baud rate and reduce the complexity of 100G/200G transmission components. Coherent DSP adopts high-performance HD-FEC, SD-FEC soft decision first-generation and second-generation error correction technologies.

lProvide the tunable wavelength function, and the wavelength modulation can be realized through the tunable CFP module, which can be set within the 96 wavelength range of the H-band 50GHz interval. Facilitate service opening and realize flexible wavelength allocation.

Specifications
