25G/40G Transceivers

QSFP28 to SFP28 Adapter (QSA) Module

Compliant to industry standards: SFF-8665
Compliant to industry standards: SFF-8432
1 independent duplex channels operating at 25Gbps, also support for 10Gbps, 5Gbps data rates
Operating case temperature: -20 to 85℃
Product description: 1 independent duplex channels operating at 25Gbps, also support for 10Gbps, 5Gbps data rates
INQUIRY EMAIL

Product Description

The Anycoms QSFP28 to SFP28 Adapter (QSA) Module offers 25 Gigabit Ethernet connectivity for Quad Small Form-Factor Pluggable (QSFP28)-only platforms. It allows smooth and cost-effective migration to 100 Gigabit Ethernet by providing an option to use lower-speed Enhanced Small Form-Factor Pluggable (SFP28) modules in empty QSFP28 ports or when the other end of the network is running at lower speeds.

The QSA Module interoperates with all major optical modules and direct attached copper cable vendors. Its design assures minimum loss on the conversion path between the QSFP28 cage and the SFP28 receptacle. The high-speed data channel of the SFP28 receptacle is connected to lane 1 of the QSFP28 connector. The three remaining channels on the QSFP28 connector are not connected. With this adapter, customers have the flexibility to use any SFP28 module or cable to connect to a lower-speed port on the other end of the network. This flexibility allows a cost-effective transition to 100 Gigabit Ethernet by maximizing the use of high-density 100 Gigabit Ethernet QSFP28 platforms. This adapter supports all SFP28 optics and cable reaches. Compatible switch models and SFP28 modules. A list of SFP28 modules that can be plugged into the QSA module is provided in Table 1

The ACS-QSAM is qualified for 10GbE SFP+ and 1GbE SFP transceivers meeting the Small Form Factor Pluggable (SFP) Transceiver Multi-source Agreement (MSA).The QSA module provides a solution for integrating systems using different vendors ‘equipment, is vendor agnostic and provides a direct path to the SFP port unit’s memory.

Features

l Trouble-free installation and network bring-up

l Compliant to industry standards: SFF-8665

l Compliant to industry standards: SFF-8432

l Precision process control for minimization of pair-to-pair skew

l 1 independent duplex channels operating at 25Gbps, also support for 10Gbps, 5Gbps data rates

l All-metal housing for superior EMI performance

l 100ohm differential impedance system

l Operating case temperature: -20 to 85℃

l Low insertion loss

l Low crosstalk

l Secure latching mechanism
