Features
l Support 4x25GBASE-SR application
l Compliant to QSFP28 MSA SFF-8636 and SFP28 MSA SFF-8431 and SFF- 8472
l Multi rate of up to 25.78125Gbps per lane
l Transmission distance up to 50m
l +3.3V single power supply
l Low power consumption
l UL certification cables (optional)
l Operating temp Commercial: 0°C to +70 °C
l RoHS compliant
Applications
l 4x25Gbe-SR
l Other optical links
Electrical Characteristics for QSFP28
|
Parameter |
Symbol |
Min. |
Typ. |
Max. |
Units |
Notes |
|
|
ModSelL |
Module Select |
VOL |
0 |
- |
0.8 |
V |
|
|
Module Unselect |
VOH |
2.5 |
- |
VCC |
V |
|
|
|
LPMode |
Low Power Mode |
VIL |
0 |
- |
0.8 |
V |
|
|
Normal Operation |
VIH |
2.5 |
- |
VCC+0.3 |
V |
|
|
|
ResetL |
Reset |
VIL |
0 |
- |
0.8 |
V |
|
|
Normal Operation |
VIH |
2.5 |
- |
VCC+0.3 |
V |
|
|
|
ModPrsL |
Normal Operation |
VOL |
0 |
- |
0.4 |
V |
|
|
IntL |
Interrupt |
VOL |
0 |
- |
0.4 |
V |
|
|
Normal Operation |
VoH |
2.4 |
- |
VCC |
V |
|
|
|
Parameter |
Symbol |
Min. |
Typ. |
Max. |
Units |
Notes |
|
|
Electrical transmitter Characteristics |
|||||||
|
Differential Date Input Swing |
Vin,P-P |
200 |
- |
1600 |
mV |
|
|
|
Input Differential Impedance |
ZIN |
90 |
100 |
110 |
Ω |
|
|
|
Tx_Fault |
Normal Operation |
VOL |
0 |
- |
0.8 |
V |
|
|
Transmitter Fault |
VOH |
2.0 |
- |
VCC |
V |
|
|
|
Tx_Disable |
Normal Operation |
VIL |
0 |
- |
0.8 |
V |
|
|
Laser Disable |
VIH |
2.0 |
- |
VCC+0.3 |
V |
|
|
|
Electrical Receiver Characteristics |
|||||||
|
Differential Data Output Swing |
Vout |
400 |
- |
800 |
mV |
|
|
|
Bit Error Rate |
BER |
- |
- |
E-12 |
- |
|
|
|
Output Differential Impedance |
ZD |
90 |
100 |
110 |
Ω |
|
|
|
Rx LOS |
Normal Operation |
VOL |
0 |
- |
0.8 |
V |
|
|
Lose Signal |
VoH |
2.0 |
- |
VCC |
V |
|
|
