Features
l Support 40GBASE-SR4/QDR application
l Compliant to QSFP+ Electrical MSA SFF-8436
l Multi rate of up to 10.3125Gbps
l +3.3V single power supply
l Transmission distance up to 300m
l Low power consumption
l Operating case temp Commercial: 0°C to +70 °C
l UL certification cables (optional)
l RoHS compliant
Applications
l InfiniBand QDR, SDR, DDR
l Other optical links
l 40GBASE-SR4 at 10.3125Gbps per lane
l Servers, switches, storage and host card adapters
Electrical Characteristics
|
Parameter |
Symbol |
Min. |
Typ. |
Max. |
Units |
Notes |
|
|
ModSelL |
Module Select |
VOL |
0 |
- |
0.8 |
V |
|
|
Module Unselect |
VOH |
2.5 |
- |
VCC |
V |
|
|
|
LPMode |
Low Power Mode |
VIL |
0 |
- |
0.8 |
V |
|
|
Normal Operation |
VIH |
2.5 |
- |
VCC+0.3 |
V |
|
|
|
ResetL |
Reset |
VIL |
0 |
- |
0.8 |
V |
|
|
Normal Operation |
VIH |
2.5 |
- |
VCC+0.3 |
V |
|
|
|
ModPrsL |
Normal Operation |
VOL |
0 |
- |
0.4 |
V |
|
|
IntL |
Interrupt |
VOL |
0 |
- |
0.4 |
V |
|
|
Normal Operation |
VoH |
2.4 |
- |
VCC |
V |
|
|
|
Electrical transmitter Characteristics |
||||||
|
Differential Date Input Swing |
Vout |
200 |
- |
1600 |
mV |
|
|
Output Differential Impedance |
ZD |
90 |
100 |
110 |
Ω |
|
|
Electrical Receiver Characteristics |
||||||
|
Differential Data Output Swing |
Vin,P-P |
350 |
- |
800 |
mVPP |
|
|
Bit Error Rate |
BER |
|
|
E-12 |
|
1 |
|
Input Differential Impedance |
ZIN |
90 |
100 |
110 |
Ω |
|
